SIEMENS ASM Type X2 • Inline SMD assembler • Portal 1 DLM3 RV12 with • Camera • 18x18 (Typ28) • Portal 2 DLM3 RV6 with camera • 27x27 (Type 27 High Resolution) • Both portals with Multicolor Cam. • Repeatability: +/- 12.5μm • PCB size (L x W) • 50x50mm2 to 450x508mm2 • Placement accuracy up to • ± 30μm, ± 0.05° at 4 sigma • Condition: very good • Location warehouse ​

16 x 8mm 16 x 8mm 2 x 16mm + 2 x 12mm + 10 x 8mm Ustawienie skoku na 11 i 12 torze na Dipswitch Wibracyjny

• Inline reflow oven • Preheat: 7 top/7 bottom • Solder zone: 3 above/3 below • Power cooling with 4 zones • Working width: 45 – 580 mm • SMEMA interface • Year of construction 06/2011 • Process chamber cleaned • Condition: good • Location warehouse
