In-line AOI for up to 650mm PCBs | Pacman-2 Chassis | Clearance +40/-35mm (option +60) | 15u High Grade TC Lens | 30mm Z-Axis | 3-Angle Coax/W/R LED sources | Lead screw Servo driven XY head | 5Mpixel colour camera USB3 Vision | Excluding Mac Computer/Monitor/Keyboard/Mouse | Clamps up to 4mm PCBs | PCB support lift included Price for a new machine : 80.500€

Semi-Automatic Stencil Printer DIMA HS-100 This device is known for its high precision and versatility, thanks to its robust construction and motor-driven printing head, which moves on linear bearings. All printer settings can be precisely adjusted using an intuitive Windows-based interface, allowing for perfect configuration for every type of printed circuit board. The self-learning feature ensures quick and easy determination of the correct board position, simplifying operations and speeding up the production process.

SIEMENS ASM Type X2 • Inline SMD assembler • Portal 1 DLM3 RV12 with • Camera • 18x18 (Typ28) • Portal 2 DLM3 RV6 with camera • 27x27 (Type 27 High Resolution) • Both portals with Multicolor Cam. • Repeatability: +/- 12.5μm • PCB size (L x W) • 50x50mm2 to 450x508mm2 • Placement accuracy up to • ± 30μm, ± 0.05° at 4 sigma • Condition: very good • Location warehouse ​
