Good working condition. Localisation Torun Poland

Machine brand new from 2023 This Quadra DVC Evo keep the high level features of the EVO series P&P and is configured with a large vacuum working plate, especially useful for assembling membrane keyboards with metal domes and leds. It comes with a double dispenser sets (volumetric Techcon TS7000 & Time pressure). Vaccum plate X / Y : 690 mm x 595 mm 16 feeders 8mm Working area with the 2 dispensors : 315 mm x 470 mm

Konfiguracja standardowa: Integral Machine Mounted Monitor and PC Inerted Nitrogen System Auto Solder Top-up (Wire Feed) & Solder Level Detect Single Titanium Drop Jet Fluxer - 200 Micron Internal Fume Extraction Colour Programming Camera Universally Adjustable Tooling Carriers 508mm (X) x 457mm (Y) (20” x 18”) Maximum PCB Handling Size Manual Fiducial Correction System PillarPAD Offline Programming Package Thermal Nozzle Calibration System using Integrated Setting Camera (requires manual correction) PillarCOMMX Windows Software Solder Wave Height Measurement Process Viewing Camera Multilevel Password Security System Lead-Free Capability Set of AP Solder Tips (2.5mm, 3mm, 3.5mm, 4mm, 5mm, 6mm, 8mm, 10mm & 12mm) Standard Production Data Export (CSV File with Configurable Board Process Data) Accessory Kit Plus dodatkowe wyposażenie: Top Side IR Pre-Heat Closed Loop Thermocouple Top-Side Pre-Heat Control Initial Lead-Free Solder Fill – SAC305 Nitrogen Analyser - (Measures the oxygen content within the incoming nitrogen into machine). Real Time PCB Warp Correction System X, Y & Z Axis Encoders Vacuum Packaging (Jade MKII)
