Machine brand new from 2023 This Quadra DVC Evo keep the high level features of the EVO series P&P and is configured with a large vacuum working plate, especially useful for assembling membrane keyboards with metal domes and leds. It comes with a double dispenser sets (volumetric Techcon TS7000 & Time pressure). Vaccum plate X / Y : 690 mm x 595 mm 16 feeders 8mm Working area with the 2 dispensors : 315 mm x 470 mm

JUKI RS-1 R - exDEMO RS-1 R Main Unit with Camera incl. standard accessoires Unique Adaptive Head System Up to 47.000 CPH ( optimum ) Automatic component height adjustment: up to 25 mm For use with Feeder-Trolleys PWB size: 50 x 50 mm (min) up to 650 x 370 mm (single clamp) up to 950 x 370 mm (double clamp) On-The-Fly laser recognition head (LNC120-8) Board offset correction camera - left (BOC-Camera) Standard Vision Camera VCS I (54mm) Automatic nozzle change station with 45 Slots Support of large nozzle ATC (optional) Nozzle No. 7500 = 8 Nozzle No. 7503 = 1 Nozzle No. 7504 = 6 Nozzle No. 7505 = 2 Nozzle No. 7506 = 2 Nozzle No. 7507 = 2 Nozzle No. 7508 = 1 Support Pins: 12 Operational panel with touch screen (machine front side) Feeder float detection sensor (front and rear) Bad mark reading with board offset correction camera Height measurement system HMS Signal tower with buzzer Operation Manual and Parts List (Electronic Format) Serial Number R1R3J3803 40215186 Trolley for RF Feeder RS-1 R and XL (NEW) 49119100 IFS NX feeder verification / IFS-NX CAN Machine Upgrade 40075909 Flexline CAD 40189363 JaNets Basic Editor System RF08AS Intelligent 8 mm Tape Feeder (RF-Type) RF12AS Intelligent 12 mm Tape Feeder (RF-Type) RF16AS Intelligent 16 mm Tape Feeder (RF-Type)
